Description

Haier 1 Ton TurboCool Non-Inverter

Capacity and Parameters

• Type : Inverter
• TR (Ton Range) : 1 Ton
• BTU/h : 12,000
• Rated Cooling Capacity (W) : 3480 (500~3850)
• EER (W/W) : 3.05
• Power Supply (Volt/Phase/Hz) : 1/230/50HZ
• Rated Power Input (W) : 1140 (150~1550)
• Rated Current (A) : 5 (0.7~6.9)
• Max. Current (A) : 6.9
• Indoor Air Flow (Hi/Mi/Lo) m³/h : 650

---

Key Components

• Compressor Type : Rotary
• Refrigerant Type : R32
• Refrigerant Standard (Kg) : 0.6
• Refrigerant Pipe Diameter (mm) : Liquid Side/Gas Side – 6/9
• Evaporator/Condenser : 100% 7mm Grooved Copper
• Heat Exchangers : Golden Fin

---

Noise Levels

• Indoor Noise Level (Hi/Mi/Lo) [dB(A)] : 41/38/35
• Outdoor Noise Level [dB(A)] : 52

---

Airflow Direction

• Up & Down : Auto
• Left & Right : Auto

---

Dimensions and Weight

Net Weight

• Indoor Unit (Kg) : 10.0
• Outdoor Unit (Kg) : 23.0

Net Dimensions (WxDxH)

• Indoor Unit (mm) : 805 x 200 x 292
• Outdoor Unit (mm) : 700 x 245 x 544

Package Dimensions (WxDxH)

• Indoor Unit (mm) : 876 x 272 x 365
• Outdoor Unit (mm) : 819 x 320 x 592

---

User Functions

• Wi-Fi : No
• UVC Technology : No
• Energy Saving : Yes (Up to 65%)
• Dry Mode : Yes
• Self-Clean : Yes
• ECO Mode : Yes
• Turbo Function : Yes
• Auto Restart Function : Yes
• Sleep Mode : Yes
• Low Noise : Yes
• Timer : Yes
• Quick & Easy Installation : Yes
• Child Lock : Yes

---

Warranty

• Compressor : 12 Years
• Spare Parts and Components : 4 Years
• After-Sales Service : 2 Years
