Description

Product is In Stock

Capacity and Parameters

• Type : Inverter
• TR (Ton Range) : 1.5 Ton
• BTU/h : 18,000
• Rated Cooling Capacity (W) : 5300 (700~5600)
• EER (W/W) : 3.03
• Power Supply (Volt/Phase/Hz) : 1/230/50HZ
• Rated Power Input (W) : 1750 (260~2200)
• Rated Current (A) : 8 (1.1~9.6)
• Max. Current (A) : 9.0
• Indoor Air Flow (Hi/Mi/Lo) m³/h : 800

---

Key Components

• Compressor Type : Rotary
• Refrigerant Type : R32
• Refrigerant Standard (Kg) : 0.85
• Refrigerant Pipe Diameter (mm) : Liquid Side/Gas Side – 6/12
• Evaporator/Condenser : 100% 7mm Grooved Copper
• Heat Exchangers : Golden Fin

---

Noise Levels

• Indoor Noise Level (Hi/Mi/Lo) [dB(A)] : 46/42/38
• Outdoor Noise Level [dB(A)] : 55

---

Airflow Direction

• Up & Down : Auto
• Left & Right : Auto

---

Dimensions and Weight

Net Weight

• Indoor Unit (Kg) : 11.5
• Outdoor Unit (Kg) : 32.5

Net Dimensions (WxDxH)

• Indoor Unit (mm) : 875 x 217 x 307
• Outdoor Unit (mm) : 800 x 280 x 553

Package Dimensions (WxDxH)

• Indoor Unit (mm) : 945 x 296 x 390
• Outdoor Unit (mm) : 902 x 375 x 614

---

User Functions

• Wi-Fi : No
• UVC Technology : No
• Energy Saving : Yes (Up to 65%)
• Dry Mode : Yes
• Self-Clean : Yes
• ECO Mode : Yes
• Turbo Function : Yes
• Auto Restart Function : Yes
• Sleep Mode : Yes
• Low Noise : Yes
• Timer : Yes
• Quick & Easy Installation : Yes
• Child Lock : Yes

---

Warranty

• Compressor : 12 Years
• Spare Parts and Components : 4 Years
• After-Sales Service : 2 Years
